Destroy or Die Mazda MX5 Miata NA NB Front Super Knuckle

Mazda MX5 Miata NA NB Front Super Knuckles

by Destroy Or Die
Availability:
in stock, ready to be shipped
£439.98 - £439.98
£439.98
£439.98 - £439.98
£439.98

Elevate your MX5's performance with our Front Super Knuckles, designed for NA and NB models. The massive steering angle combined with the roll centre correction make fast, high-angle drifts precise and predictable - even for backwards entries!

Features:

  • Fits all NA & NB models - direct bolt-on.
  • These are drop knuckles with 40mm drop creating roll centre correction which eliminates bump steer giving superb control and steering input (adjust coilovers to compensate).
  • No increase in weight over standard knuckles.
  • No ABS mounting points.
  • Use OEM ball joints.
  • Use OEM wheel bearings.
  • Return your stock knuckles (preferably fully stripped) for a £50 refund! Contact us for more information.

Don't forget to buy Extended Front Brake Lines - Available here!

Contents:

  • 1x Front left super knuckle.
  • 1x Front right super knuckle.

Warnings:

  • While these will technically bolt to factory LCAs - we highly recommend combining them with our high-clearance adjustable lower control arms to give enough wheel clearance.
  • To retain pre-install ride height adjust coilovers to compensate for the 40mm drop, otherwise your car will be lowered.
  • Fitting by an experienced mechanic is strongly recommended. Destroy Or Die are not responsible for any damage caused due to incorrect fitting or assembly.
  • Designed for off-road/track use only. Not for road use.

Suggested Alignment:

  • Front:
    • Camber -5
    • Caster 5
    • Toe 0
  • Rear:
    • Camber 0
    • Toe 0
  • Rear toe-in will make for snappier transitions, while front toe-out can aid with turn-in.
  • However, our advice is to learn and experiment with different settings to suit the car, track and driving style.

Click HERE to see Project 380's fantastic fitting guide and familiarise yourself with the parts before yours arrive.

Not the only part you're buying? Scroll down to save money and get these as part of a bundle deal!
